PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant

Certification
China Zhengzhou MG Industrial Co.,Ltd certification
China Zhengzhou MG Industrial Co.,Ltd certification
Customer Reviews
Dear Jason Liu It is very nice to hear from you as long time we no contact each other. By the way, the machine which we bought from you since 2017 we already assembled and being use from that time until now. So far there is no problem with the machine, so it can indicates that your machine is very good with the quality.

—— Ravin

Hello Zoey, Hope it is going well and safe with you guys in the strange new world we live in. It has been a year now since we installed Dry mortar plant and operating in SA. your machine is very good. As our output is increasing, I am reviewing options of installation of a second production line. Can you please send me a quote for a new plant ?

—— Francois

Hello Jason , how are you? We as a Company, we really appreciate your efforts on installing the plant on time, we really are thankful on your workers, they work hard to finish the plant and we helped them a lot but we finished on time without any problem... Also we tryed to be really nice and friendly with the workers so I hope they had a great t

—— Merita

Hi Zoey, All is well, How about you ? Yes, MG machine are working good. Thank you for your support. With this kind of machine we can make our own pre bag grout. Then consultants can’t complain anymore.

—— Prathamesh

I'm Online Chat Now

PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant

PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant
PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant
PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant

Large Image :  PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant

Product Details:
Place of Origin: China
Brand Name: MG
Certification: CE BV ISO 9001:2008
Model Number: MGDM3.7
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Stand seaworthy packaging
Delivery Time: 30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5 sets per month

PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant

Description
Raw Material: Sand,Cement,Gypsum,etc Application: Dry Powder Mixing
Capacity: 10-50 T/h Color: Grey/White/Blue Or Customized
Power: 80kw-120kw Workers: 3-4 Persons
Size: 600-800m2 Formula: Provided
After-sales Service Provided: Engineers Available To Service Machinery Overseas Packaging: 10-50kg/bag Automatic Packing Machine
High Light:

PLC Control Dry Mortar Mixer Machine

,

Cement Wall Putty Mixer Ceramic Plant

,

Dry Mortar Mixing Machine 80kw

PLC Control Dry Mortar Mixing Machine Tile Adhesive Manufacturing Plant



1,Description of PLC Control Dry Mortar Mixing Machine Tile Adhesive Manufacturing Plant.

The PLC Control Dry Mortar Mixing Machine Tile Adhesive Manufacturing Plant is an automatic powder mixing equipment. The proposed mixing station consisting of a combination of a twin-shaft mixer and a batching system can fully utilize the advantages of the batching system and the mixer. The operation is simple and convenient. The Chinese and English menus show that the status of each device is simulated and displayed with an audible and visual alarm. When working at the mixing station, after only a small number of buttons are operated, the entire work process is transferred to the computer control.



2.Advantages of PLC Control Dry Mortar Mixing Machine Tile Adhesive Manufacturing Plant.

The advantages of our Automatic dry mortar mixing equipment.



1, A high degree of intelligence. It is controlled by the control system and realizes automatic automation of automatic batching,automatic weighing, automatic feeding, automatic mixing and automatic packaging.
2, The use of tower layout structure, shorten the transmission distance and increase production efficiency.
3. The use of a biaxial mixer( Twin shaft mixer) has high mixing uniformity, and materials with large differences in physical properties such as specific gravity, particle size and shape do not easily segregate when mixed in the mixer.



Model Capacity Equipment height Total power Worker required Workshop required
2000L Mixer 10-12T/H 8-10m 80-90KW 2-3 Person 500-600m2
3000L Mixer 15-20T/H 10-14m 90-100KW 3-4 Person 600-800m2
4000L Mixer 20-30T/H 10-14m 100-120KW 3-4 Person 600-800m2
6000L Mixer 30-50T/H 15-20m 100-120KW 3-4 Person 800-1000m2
10000L Mixer 50-80T/H 20-25m 120-150KW 3-4 Person 1000-1200m2



3. Raw Material of PLC Control Dry Mortar Mixing Machine Tile Adhesive Manufacturing Plant.

Raw materials are: Cement, Sand, Gypsum, Flyash, Gelatine powder, Cellulose and Additives etc.



4. Application of PLC Control Dry Mortar Mixing Machine Tile Adhesive Manufacturing Plant.
Applications of dry mortar production line
1,Wall Putty powder
2,Masonry mortar,
3,Thin and Smooth wall mortar,
4,Water proof mortar,
5,Plaster powder,
6,Wall plastering mortar,
7,Ceramic tile adhesive mortar,

5. Configuration of PLC Control Dry Mortar Mixing Machine Tile Adhesive Manufacturing Plant.

1,Raw Material Storage Silo:

Customized volume 150T, 100T, 60T, Easy transportation, waterproof manufacturing and reasonable design.



2,Bucket elevator.

High efficient, Good sealing, Easy assemble, Environment protection, Easy maintenance.



3, Automatic weighing system of main material.

High efficient self-measurement, Highly sensitive, High accurate digital display.


4,Automatic weighing system of additives
High accuracy,high sensitive,fully automatic



5,Twin shaft agravic paddle mixer.

High Efficiency, equip with fly cut for fiber breaking, Mixing time 3-5 minutes per batch.



6,Finish Product Hopper
Reasonable design, Equip pneumatic vibrating system,High capacity


7,Automatic packing machine.

High accuracy, high speed, Equip bag auto pushing system.



8,Pulse dust collector.

High efficiency, strength dust collecting, pulse controller control.


9,Screw Type Air Compressor
High Quality, Long life Time, Energy Saving



10,Control cabinet.

Famous brand PLC, Intelligent and computer control.



6.Our company.

Zhengzhou MG Industrial Co,.Ltd,one of the leading manufacturers of building material equipment in China,always provides the customers from all over the world with professional efficient solutions to high quality machine,formula technology and special additives for more than 20 years.
The main products of the company include dry mortar plant,thermal insulation mortar production line,sand dryer powder blending machine,impulse dust collector,automatic packing machine,and so on.
MG products have been widely used in more than 1000 building materials enterprises in China,and exported to more than 50 countries,such as Canada,Russia,Korea,Malaysia,the United Arab Emirates,Argentina,Chile,Ecuador,Morocco,South Africa,Nigeria,etc.
MG will be willing to work with you to seek common development and create brilliance.
Welcome to inquiry on our products





PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant 0PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant 1PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant 2PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant 3PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant 4PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant 5PLC Control Dry Mortar Mixing Machine 50 T / H 80kw Cement Wall Putty Mixer Ceramic Plant 6



7.Our Services

Pre-sale service

1) Once got your inquiry, we will reply to you in 24 hours;
2) High quantity and quantity assured;
3)Favorable price as we are manufacturer;
4) Provide professional technical and project;
solutions online or by telephone ;
5) Well-trained and experienced staff to answer all your inquiries in fluent English and Russia;
6)OEM & ODM is welcomed. OEM brand is available;
7)Assist clients to prepare for the first construction scheme and supply foundation drawing.



After-sale service

1) Assist clients to prepare for the first construction scheme and supply foundation drawing.
2)Oversea installation and provide technical exchange, train client to operate the machine.
3) Supply spared and accessory parts at favorable price for long-term.
4)Spare part are original, authentic, good quality.
5)They can be available from stock, and sent to clients, immediately by sea, guarantee clients to receive it in shortest time.
6) Providing following up after-sale service.



7.FAQ.

1.What product can this production line make?
Our automatic dry mortar production line can make all kinds of dry mortar,such as wall putty,plaster,skim coat,ceramic tile adhesive,and so on.

2.What is the attentions we should pay when we use ceramic tile adhesive?
1).Because the adhesiveness of the tile adhesive is very large, it is necessary to pay attention to stirring evenly when using it.It is best to use an electric mixer for stirring, which can better ensure the uniformity of the tile adhesive.
2).When using tile adhesive, pay attention to protective treatment to avoid the phenomenon of tiles falling off, especially in rainy days, do not directly contact with tile adhesive to avoid reducing the adhesiveness of tiles.

3.Do you have your own factory?
We have our own factory. Located in Zhengzhou City, Henan Province, China, welcome to visit our factory.
In addition, we have long-term cooperative relationships with some excellent raw material suppliers to ensure that the prices of the products we supply are lower than other foreign trade companies.

4.What is the total cost if you start one automatic plant?
It depends on your requirements. But we can provide design services and budget assessments according to your needs. Besides, we believe that you will get the most competitive price and the best quality products. thirdly, in terms of installation: After reaching an agreement, we will send senior engineers and English translators to your country to install and operate the machine.

5.How many workers will need to operate the whole production line?
Usually 2-4 workers are enough to operate the machine.

6.How long is the guarantee period of your equipment?
12 months, during this period, we will provide you with spare parts and services for free.

7.What is the capacity of your dry mortar production line?
Usually, the production capacity of the dry mortar mixing equipment we supply is 3-30t/h as required by you, but we can also customize the dry mortar equipment according to your capacity requirements.

8. What is the area needed for the automatic dry mortar plant?
The area required for this dry mortar mixing equipment is usually 100-300 square meters.

9. What is the difference between automatic dry mortar mixing equipment and semi-automatic dry mortar mixing equipment?
1) In terms of price: more and cheaper semi-automatic dry mortar mixing equipment.
2) Silo: The automatic dry mortar mixing equipment is equipped with a silo.
3) Operators: The semi-automatic dry mortar mixing equipment requires 2-3 people to feed materials


If you are interested to our dry mortar production line, please feel free to send us inquiry or leave your contact number for us.
