Product Details:
|
| Product Name: | Dry Mortar Mixer Machine | Capacity: | 10-40T/H |
|---|---|---|---|
| Material: | Carbon Steel | Power: | 37-80KW |
| Mixing Speed: | 30-45r/min | Control System: | PLC |
| Warranty: | 12 Months | Voltage: | Customized 220V/380V/415V |
| Advantage: | Professional Manufacture | Sand Dryer: | Depends |
| High Light: | Tiles Grout Making Machine,Sand Dryer Dry Mortar Production Line |
||
Dry Mortar Production Line Tiles Grout Making Machine With Sand Dryer
Descriptions of MG Dry Mortar production line:
MG Dry Mortar Production Line abandons the traditional ground batching form and adopts the top layout mode of the tower layout, which greatly reduces the material mix delivery time, improves production efficiency, and reduces production costs. According to the production requirements, the mixing system can use 4-10m3 large-capacity gravity-free double-shaft high-efficiency mixer with short mixing time and high mixing precision. The complete set of equipment is controlled by PLC automatic control system in real time, with high degree of automation management and friendly working environment.The scope of application includes: gypsum mortar, plastering mortar, masonry mortar, thermal insulation mortar, decorative mortar, ground mortar, bonded mortar, crack-resistant mortar, tile adhesive, grouting, etc.
Detail configuration of MG Dry Mortar production line:
| Model | Simple dry mortar plant | Improved simple dry mortar plant | Semi-auto dry mortar plant | Full-auto dry mortar plant |
| Out put | 1-3t/h | 4-5t/h | 5-8t/h | 10-30t/h |
| Machine area | 20m² | 20m² | 50-60m² | 60-100m² |
| Total power | 5.5-7.5kw | 6-11kw | 24-28kw | 60-120kw |
|
Mixer volume |
3300*1050*2100mm | 2m³ | 2m³ | 2m³, 3m³, 4m³ |
| Machine height | 3-4m | 3-4m | 6-8m | 8-13m |
| Man power | 2-3person | 2-3person | 3-4person | 3-4person |
| Equipment parts |
screw conveyor, ribbon mixer, transit hopper, valve packer, air compressor, control panel |
screw conveyor, twin shaft mixer, storage tank, valve packer, air compressor control cabinet |
bucket elevator, twin shaft mixer, holding tank, valve packer, control cabinet, air compressor |
silos, screw conveyor, auto-weighing system, bucket elevator, premix tank, twin shaft mixer, holding tank, valve packer, PLC control cabinet, air compressor |
| Batching and packaging | Manual batching & Automatic packaging | Automatic | ||
Application of MG Automatic Dry Mortar Mixing Equipment:
Dry mix mortars are used in many different applications in the construction of a building. Some of these applications are universal and some others are specific to certain regions or countries. Dry Mortar Mixing Equipment can produce the following dry mortars:
| Bonding mortar | Masonry mortar, wall and floor tile adhesive mortar, anchorage mortar etc |
| Decoration mortar | Decorative plaster, inner and outer wall putty, colorful decoration mortar etc |
| Protection mortar | Water-proof mortar, anti-corrosion mortar, self-leveling mortar, wear resistance mortar, thermal insulation mortar, sound insulation mortar, repair mortar, mildew proof mortar, shielding mortar etc. |
Bonding mortar: Masonry mortar, wall and floor tile adhesive mortar, anchorage mortar etc.
Decoration mortar: Decorative plaster, inner and outer wall putty, colorful decoration mortar etc.
Protection mortar: Water-proof mortar, anti-corrosion mortar, self-leveling mortar, wear resistance mortar, thermal insulation mortar, sound insulation mortar, repair mortar, mildew proof mortar, shielding mortar etc.
We are professional manufacturer of dry mortar plant and sand dryer plant over 20 years, providing turnkey project from working site design, foundation drawing, installation and debugging, worker training, latest formula, chemicals, after-sale and life time technical support.
