Full Automatic Dry Mortar Mixing Machine For Wall Putty Making

Full Automatic Dry Mortar Mixing Machine For Wall Putty Making
Full Automatic Dry Mortar Mixing Machine For Wall Putty Making Full Automatic Dry Mortar Mixing Machine For Wall Putty Making

Large Image :  Full Automatic Dry Mortar Mixing Machine For Wall Putty Making

Product Details:
Place of Origin: Henan, China
Brand Name: MG
Certification: CE, ISO, SGS,BV
Model Number: MGDM-3.7
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard seaworthy packing-Wooden box packing and bubble wrap packing
Delivery Time: 20-25 working days from paid advance payment
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 30 Sets/Month

Full Automatic Dry Mortar Mixing Machine For Wall Putty Making

Product Name: Automatic Dry Mortar Mixing Machine Application: Tile Adhesive And Wall Putty Making
Mixer Type: Twin Shaft Mixer Voltage: 220V-440V, 50/60Hz Adjustable
Packing: Automatic Weighing And Packing Mixing Time: 3-5 Minute
Worker Required: 3-4 Person Formula: Provided
Installation: We Arrange Engineer To Oversea For Guiding Installation Control System: Intelligent PLC And Computer Control
High Light:

Full Automatic Dry Mortar Mixing Machine


Intelligent PLC Dry Mortar Mixing Machine


Wall Putty Dry Mortar Plant


10-30 T/H Full Automatic Dry Mortar Mixing Machine


1. Description Of MG Automatic Dry Mortar Mixing Machine:


Dry mortar is widely used in the construction field. According to different applications, it is pre-mixed and packaged according to the formula. The advantages of stable and excellent product quality, convenient use and environmental protection are maintained. The production line consists of two parts: sand drying and screening section, material batching and packaging section. For the packaging system, the bag packaging machine or tank loading system can be selected according to the actual requirements of customers.


The Production Capacity You Can Choose


A)  3T/H Dry Mortar Mixing Machine

B) 4-5T/H Dry Mortar Mixing Machine

C) 6-8T/H Dry Mortar Mixing Machine

D) 10-12T/H Dry Mortar Mixing Machine

E) 20-25T/H Dry Mortar Mixing Machine

F) 30T/H Dry Mortar Mixing Machine

G) 40-50T/H Dry Mortar Mixing Machine


2. Mechnical principle of MG automatic dry mortar plant:


The non-gravity mixer works in the principle of mixing the materials in air countercurrent. The double shaft paddles are in

stalled inside the drum and rotated in the opposite direction to each other. Each of the paddles is designed in rational separation distance and angle degree through the scientific calculation. When the materials are thrown to the air current inside drum by the force from the rotating paddles, the non-gravity force will be instantaneously generated and the materials will be thrown to the opposite area. The space between the twins shafts will be formed a fluidized non-gravity area and an air eddy current, in the bottom part, an air flowing layer also will be formed inside the drum. As a result, the materials are taken the three-dimensional compound motions, in order to be evenly, rapidly and circularly mixed in all aspects.

The machine can be widely applied in drying and mixing the chemical materials, metal materials, construction materials, coating materials, resins, agricultural materials, feeding stuffs, powder materials and etc.


3. Classifications of MG Automatic Dry Mortar Plant:


According to the structure, the dry mortar plant can be classified as four different types: Tower type, Stair type, Block type and Flat type. According to the operating mode, the dry mortar production line can be classified as manual type, auto-manual type, auto type


4. Advantage of MG automatic dry mortar plant:


(1)There are several materials discharging modes for selecting, which include the manual mode, electrical mode and pneumatic mode.

(2)The fiber can be rapidly separated by the high speed rotating blades.

(3)The air-phase balancing device is installed to mix the materials more even.

(4)The compound structure of paddles can largely reduce the cost of maintenance.

(5)The materials are discharged through the big gate, which can reduce the blind areas inside the mixer, make the discharging procedure cleaner and faster.

(6)It can mix the solid-solid (powder and power) and solid-liquid (powder and liquid), and also take drying operation.

(7)The speed of mixing is fast, it only takes about 2-3 minutes to mix the ordinary powders.

(8)The machine can be operated in confined space, which is running reliably and convenient in maintenance.


5. Parameter of MG full automatic dry mortar plant :


Model 2000L Mixing Plant 3000/4000L Mixing Plant 6000L Mixing Plant 10000L Mixing Plant
Capacity 10-12T/H 15-30T/H 30-40T/H 50-60T/H
Machine Height 8-9m 9-10m 11-12m 13-15m
Total Power 80-90KW 90-100KW 100-120KW 120-150KW
Worker Required 2-3 person 3-4 person 3-4 person 3-4 person
Workshop Required 500-600㎡ 600-800㎡ 800-1000㎡ 1000-1500㎡
Bag Belt Conveyor B500X5000mm B500X5000mm B500X5000mm B500X5000mm
Pallet Wrapping Machine Provide Provide Provide Provide
Sand Dryer Provide as requirement Provide as requirement Provide as requirement Provide as requirement
HS code 8474390000 8474390000 8474390000 8474390000



7. Application of MG automatic dry mortar plant:


MG automatic dry mortar plant can be used to produce the following dry mortars: Bonding mortar: Masonry mortar, wall and floor tile adhesive mortar, anchorage mortar etc. Decoration mortar: Decorative plaster, inner and outer wall putty, colorful decoration mortar etc. Protection mortar: Water-proof mortar, anti-corrosion mortar, self-leveling mortar, wear resistance mortar, thermal insulation mortar, sound insulation mortar, repair mortar, mildewproof mortar, shielding mortar etc.


Full Automatic Dry Mortar Mixing Machine For Wall Putty Making 0


8. Our company


Zhengzhou MG industrial Co., Ltd, the leader of Full Automatic dry mortar Production Line!


Zhengzhou MG industrial Co., Ltd, was verified by ISO9001 quality control system, awarded as Henan first-class science and technology enterprise by government. We were Henan observe quality and credibility enterprise union governing unit in 2012.


Our company engaged in the dry powder mixing equipment R&D, production, sales and construction, providing most efficient turnkey solutions to our clients in green building energy-saving insulation and green wall (building) materials manufacturing equipment, production technology and construction program.


Our main products include dry mortar production line, thermal insulation mortar production line, sand dryer, powder blending machine, concrete mixer, and others.


9. FAQ


1, How about the investment of this project?
A: Our engineer can design the dry mortar plant as your requirements and your budget, different dry mortar plant investment are different. Low capacity low cost, we will provide you cost effective solutions as your requirement.


2, What's the difference between full automatic dry mortar plant and Semi-automatic dry mortar plant ?
A: (1) Semi-automatic dry mortar plant is cheaper than full automatic dry mortar plant.
(2) Semi-automatic dry mortar plant do not need to equip silos while full automatic dry mortar equip material silos.
(3) Semi-automatic dry mortar is manual feeding and automatic weighing and packaging, full automatic dry mortar plant is automatic feeding and automatic weighing and packaging.


3, How many person required to operate this dry mortar plant ?
A: Usually 2-4 workers are enough to operate this dry mortar plant.


4, What equipment and services you can provide?
A: We can provide you turnkey solution of dry mortar plant from working site planning to dry mortar machines, transportation, installation and training, formula of dry mortars, after-sales services, life time technical support etc.


5, What is the area required for this dry mortar plant ?
A: According to the capacity of the dry mortar plant, the area required 20 m2.


6, What is the total power consumption (KW) of this dry mortar plant?
A: It is 20-80W based on the capacity of the dry mortar plant.


7, What is the capacity of your dry mortar plant?
A: We have dry mortar plant with capacity 3-30T/H as your requirement, and also we can customize the dry mortar plant as your capacity requirement.


8, How long is the guarantee period?
A: 12 months, within this period, we provide you spare parts and services for free.


9, Can you install the dry mortar plant in my country?
A: Yes, we will send engineers to your country to install equipment and train your workers to operate the machine.


10, If you want to know more of our dry mortar plant, please send us inquiry or contact us directly.
