Product Details:
|
| Condition: | New | Application: | Bag Or Box Palletizer |
|---|---|---|---|
| Place Of Rigin: | Henan, China( Mainland) | Color: | Grey/White/Blue Or Customized |
| Warranty: | 12 Months | After-sales Services: | Engineer Available To Service Machinery Overseas |
| Technical Support: | Long Life Time Support Provide | ||
| High Light: | robotic bag palletizer,bag palletizer |
||
2018 China professional manufacturer new product good quality automatic palletizer machine
Description of MG palletizer machine:
Intelligent Smart Automatic Palletizer Machine for bag packaging
Technical parameter of MG automatic palletizer machine:
| Rated payload | 180Kg |
| Reach | 3130mm |
| Number of axes | 4 |
| Mounting position | Floor |
| Weight of robot | 1400KG |
| Pose repeatability | ±0.5mm |
| Floor area | 900*900mm |
Axes data
All specifications in the “Range of motion” column are referred to the mechanical zero of the robot axis concerned.
| Axes | Range of motion | Speed |
| software--limited | ||
| A1 | ±180° | 85°/s |
| A2 | -10°to-130° | 105°/s |
| A3 | +25°to+135° | 105°/s |
| A4 | ±300° | 170°/s |
MG robotic palletizer is able to handle heavy payloads and have large horizontal and vertical reaches that allow parts to be palletized from varying distances.
Robot palletizing can be seen in many industries including food processing, manufacturing, and shipping. There are several modles available including KR180 , R3200PA .
To learn more about LONGTAI Robots palletizing built for applications contact us to request a quote.
